Engine Analyzer and Boost Controller


    Software Updates

    Stealth/3000GT ECU version

    UPDATE415.zip - version 4.15, supports new LCDBC Add-on cable.  This cable can read all computers on our vehicles such as ABS, SRS, Automatic Tranny, Climate control, ECS, Cruise, ETACS.

    AEM ECU version

    AEMUPDATE400.zip - version 4.00 supports the LCDBC Add-on device, so you can read the SRS, ABS, ETACS, Cruise, ECS, A/C Climate control, and automatic transmission computer.




    DOCUMENTS

    LCDBC  User Manual - Stealth/3000GT  ECU version

    LCDBC Installation Manual - Stealth/3000GT ECU version

    LCDBC AEM EMS ECU version,  setup guide

    LCDBC AEM EMS ECU version, User Manual

    GALLERY of customer installs





    REPLACEMENT LCDBC parts

      LCD display connector, rotary encoder connector, etc uses this:

      JST XH crimp pins, Part number SXH-001T-P0.6, or Digikey part number 455-1135-1-ND

      Older LCDBC units used smaller connectors for their external pressure sensors, Ext1, and Ext2 :

      JST EH crimp pins, Part number SEH-001T-P0.6, or Digikey part number 455-1042-1-ND

      LCD screen:

      Digikey part number, NHD-0216K1Z-FS(RGB)-FBW-REV1-ND

      You're welcome to order any replacement parts from me, just send a message.

    ORDER

    3 LCDBC units in stock, ready to ship.

    Purchase from these websites:

    http://www.3si.org/forum/f4/lcdbc-752914/

    or

    http://www.3sgto.org/threads/14932-LCDBC-tach-version-boost-controller-and-ECU-monitor

    Price is $230 USD, shipping included to USA and Canada. Includes  your choice of OBD1 (91-93), or OBD2/MUT cable (94-99).



    Options: External pressure sensor harness +$5
    Options: External sensor 1 harness +$5
    Options: External sensor 2 harness +$5
    Options: 3D printed plastic (black) air vent adapter +$5
    Options: 3D printed plastic (black) coin tray + $15
    Options: 3D printed plastic (black) ashtray + $20

    Paypal address:   antero_jussila   @   yahoo.com



    TIPS

    If you disconnect/reconnect the connectors often, you might separate the pins from the wires.

    Pulling on the wires is a bad idea, use a flat head screw driver to pry the connectors from the LCDBC box.

    If you hot-glue the connectors, this will give it stength.



    TFT LOGGER

    A Screen Reset fix for batch 1 & batch 2 --  if yours doesn't power on consistently.

    TFTFlasher111.zip - fixed logging bug (removed Strings C++ memory leak), you can now

    reset the TFT Logger by pressing + and - buttons simultaneously.  O2 voltages had to be divided by 100 in the datalog, this is fixed.  Injector Duty Cycle now represented with 1 decimal place.



    OLD LCDBC DEVICES

    Change LCDBC v2 to v3 with Microprocessor upgrade

    old LCDBC v2 User Manual

    Update227.zip - for LCDBC v2 with big memory microprocessor

    Update104.zip - v1.04 for LCDBC v2 AEM version

    Update18.zip - v1.8 for LCDBC v1




    email:    antero_jussila    @  yahoo.com
